Model: AT-R807
The Wireless Mini AP supports 802.11 N wireless transmission standards and is backward compatible with IEEE802.11 b/g standards. It supports data rate up to 300 Mbps. The Wireless Mini AP is Mainly used for providing free WIFI service in big area such as factory, community, street or etc. It supports WEP, WPS and WPA/WPA2 of personal and enterprise encryption standards.
Universally complies with IEEE 802.11n, IEEE 802.11g and IEEE 802.11b standards.
Supports AP and Repeater modes.
Provides one 10/100M LAN port
WLAN 802.11n for wireless high-speed access up to 300Mbps, ideal for video streaming, online gaming and Internet calling.
Easy Setup Assistant provides quick & hassle free installation.
Supports SSID broadcast control.
WMM and WMM-APSD supported.
Internal Omni Directional antenna.
Supports 64/128/152-bit WEP, complies with 128bit WPA(TKIP/AES), supports MIC, IV Expansion, Shared Key Authentication, IEEE 802.1X.
User interface supports free WEB software updates.
Mini and pocket design, ideal for home or travel use.
300M Wireless AP with Extended Range
Supports far-distance transmission, 100 meters indoor, 300 meters outdoor (depends on the environments around)
Supports remote/local Web management and web upgrade
|
Standards |
IEEE 802.11n, IEEE 802.11g, IEEE 802.11b |
|
Wireless Signal Rates With Automatic Fallback |
11n: Up to 300Mbps (Dynamic) 11g: Up to 54Mbps (Dynamic) 11b: Up to 11Mbps (Dynamic) |
|
Frequency Range |
2.4-2.4835GHz |
|
Wireless Transmit Power |
<20dBm (EIRP) |
|
Modulation Type |
DBPSK, DQPSK, CCK, OFDM |
|
Receiver Sensitivity |
135M: -68dBm@10% PER 54M: -68dBm@10% PER 11M: -85dBm@8% PER |
|
Wireless Security |
64/128bit WEPWPA/WPA2, WPA-PSK/WPA2-PSK(TKIP/AES) |
|
Interface |
1 10/100M RJ45 Port |
|
Antenna Type |
2* 2dBi Antenna |
|
Power supply |
Input AC100~240V Output DC 5V/1A |
|
Operating Temperature |
0°C~40°C (32°F~104°F) |
|
Storage Temperature |
-40°C~70°C (-40°F~158°F) |
|
Relative Humidity |
10% ~ 90%, non-condensation |
|
Storage Humidity |
5%~95% non-condensing |
