Model: AT-MS1003KS
The AT-MS1003KS upgrades your network to the next generation of Whole-Home Mesh Wi-Fi System. With combined wireless speeds of up to 1.2Gbps, the device provides better speeds. Simple tasks and intensive tasks like online gaming or HD video streaming can be handled by the 2.4GHz & 5GHz band concurrently. Simply press the M button on the device, all the other M1200 will be connected automatically to establish smart wireless network for whole home coverage. And with the seamless roaming feature, you can go from room to room without losing connection, creating a lag-free video call/online gaming experience when you are on the move.
*The next generation Whole-Home Mesh Wi-Fi System
*Supports 802.11ac Wave2 MU-MIMO + Beamforming Technology
*Compatible with 802.11 b/g/n/ac products
*Simultaneous Dual Band – for combined wireless speeds of up to 1200Mbps at 2.4GHz and 5GHz band concurrently.
*Easy one-touch Mesh establishing with the Mesh button.
*Advanced Wireless Security, including WEP, WPA, WPA2, as well as wireless MAC Authentication.
|
General |
|
|
Wireless Standards |
IEEE802.11a/n/ac,5GHz IEEE802.11b/g/n,2.4GHz |
|
Signal Rate |
5GHz: Up to 867Mbps 2.4GHz: Up to 300Mbps |
|
Operation Frequency |
2.4GHz and 5GHz |
|
EIRP |
2.4GHz < 20dBm, 5GHz < 23dBm |
|
Receive Sensitivity |
5GHz 11a 6Mbps: -96dBm, 11a 54Mbps: -79dBm 11ac HT20: -71dBm, 11ac HT40: -66dBm, 11ac HT80: -63dBm, 11n HT20: -72dBm, 11n HT40: -71dBm 2.4GHz 11g 54M: -77dBm 11n HT20: -74dBm, 11n HT40: -72dBm |
|
Wireless Security |
WEP, WPA / WPA2, WPA-PSK/ WPA2-PSK encryption |
|
Hardware |
|
|
Interfaces |
1 x 10/100/1000Mbps WAN/LAN Port 1 x 10/100/1000Mbps LAN Port |
|
Buttons |
Mesh Button, Reset Button |
|
Power Supply |
DC 12V 1.5A |
|
Antenna |
2 x 5dBi dual band internal antennas |
|
Dimensions (W X D X H) |
140×140×95mm |
|
Software Features |
|
|
WAN Type |
Dynamic IP/Static IP/PPPoE |
|
Operation Mode |
Gateway Mode, Bridge Mode, Bridge Mode, WISP Mode, WISP Mode |
|
DHCP |
Server, Client, DHCP Client List, Address Reservation |
|
Wireless Functions |
Multiple SSID, MAC Authentication, Universal Repeater, WDS, WPS |
|
Quality of Service |
WMM, QoS(Bandwidth Control) |
|
Port Forwarding |
Virtual Server(Port Forwarding), UPnP, DMZ |
|
VPN Pass-Through |
PPTP, L2TP, IPSec |
|
Access Control |
Local Management Control Rule Management |
|
Firewall Security |
White/Black list IP Address Filter/MAC Address Filter/URL Filter Rule Schedule |
|
Management |
Access Control Local Management Remote Management Backup & Update & Restore to factory default System log |
|
Internet Protocol |
IPv4 |
|
Environment |
|
|
Operating Temperature |
0°C~40°C (32°F~104°F) |
|
Storage Temperature |
-40°C~70°C (-40°F~158°F) |
|
Relative Humidity |
10%~90%, non-condensing |
|
Storage Humidity |
5%~95%, non-condensing |
|
Certifications |
CE, RoHS |
|
Package Contents |
|
|
Package Contents |
1 x Mesh Router,2X Mesh repeater 1x Power Adapter 1 x Quick Installation Guide 1 x Ethernet Cable |
