HARDWARE FEATURES

Standards and Protocols

IEEE 802.3i, IEEE 802.3u, IEEE 802.3ab , IEEE 802.3x

Interface

24 10/100/1000Mbps RJ45 Ports (Auto Negotiation/Auto MDI/MDIX)

Network Media

10BASE-T: UTP category 3, 4, 5 cable (maximum 100m)

100BASE-TX/1000BASE-T: UTP category 5, 5e or above cable (maximum 100m)

Fan Quantity

Fanless

Power Consumption

Maximum: 14.6W (220V/50Hz)

Power Supply

100-240VAC, 50/60Hz

PERFORMANCE

Switching Capacity

48Gbps

MAC Address Table

8K

Packet Forwarding Rate

35.7Mpps

Jumbo Frame

10KB

Transfer Method

Store-and-Forward

OTHERS

Certification

FCC, CE, RoHS

Package Contents

24-Port Gigabit Desktop/Rackmount Switch

Power Cord

Installation Guide

Rackmount Kits

Rubber Feet

System Requirements

Microsoft® Windows® XP, Vista™, Windows 7 or Windows 8, MAC® OS,

NetWare®, UNIX® or Linux.

Environment

Operating Temperature: 0℃~40℃ (32℉~104℉);

Storage Temperature: -40℃~70℃ (-40℉~158℉);

Operating Humidity: 10%~90% non-condensing;

Storage Humidity: 5%~90% non-condensing
