Main Chipset

Ralink RT5372

Host interface

USB 2.0/1.1 Type A

LED

Link/ Activity

Antennas

2 built-in onboard PCB antennas.

Operation Frequency

2412~2484MHz

Typical Transmit Power

802.11b (CCK) 11Mbps: 19+/-1dBm

802.11g (OFDM) 54Mbps: 15+/-1dBm

802.11n (HT20@MCS7), 14+/-1dBm

802.11n (HT40@MCS7),14+/-1dBm

Receive Sensitivity

802.11b: -88+/-1dBm

802.11g: -73+/-1dBm

802.11n (HT20), -71+/-1dBm

802.11n (HT40), -68+/-1dBm

Operation System

Windows 2000/XP/Vista/7; Linux 2.6.X; Mac OS X

Security

WEP 64/128bit , WPA, WPA2, 802.1x, and 802.11i

Cisco CCS V1.0, 2.0 and V3.0 Compliant

Voltage Range/Current

DC 5.0V ± 5% / <350mA @802.11g

Operating Temperature

-10°C - 60°C

Storage Temperature

-20°C - 70°C

Operating Humidity

RH 95% (Non-Condensing)

Storage Humidity

RH 95% (Non-Condensing)

Physical Specification

Dimensions

42*16.8*4.5mm

Weight
