Technical Standard

Chipset: Qualcomm 9600

LTE FDD B1/B3/B7/B20 Upto 150Mbps

HSPA/HSDPA/HSUPA/UMTS,

Up to 42Mbps Download,   Upload 11Mbps

EDGE 3GPP Release4, Multislot class 12, up to 237 Kbps

GPRS 3GPP Release4, Multislot class 10, up to 85.6Kbps

Frequency Band

GSM/GPRS/EDGE 850/900/1800/1900 MHz

UMTS 1800/2100 MHz

Power Class

WCDMA Power Class 3

GSM 850/900 Power Class 4

EDGE 850/900/1800/1900 Power Class E2

External Interface

UMTS/GSM Antenna Supported, Internal Antenna

USB Type Standard USB Interface

USB Speed USB 2.0 High Speed

Power Mode Powered via the USB interface

SIM/USIM Card Standard 6 PIN SIM card interface, compaliant with 3GPP 31.101 and 31.102

AT Interface 3GPP TS27.005/3GPP TS27.007 supported

Main Features

Form Factor Rotating USB Dongle

Dimension ((mm)) 79.0mm((h)) * 25.0mm(W) * 11.8mm((h)) Weight < 30gms

Visual Indicator(LED) RGB LED indicator for different state.

Languages Supported English

Zero-CD installation Supported

Operate System Supported Windows 2000 SP4/ XP SP2/ VISTA, Windows 7 Mac

OS X 10.4.9 or higher, up to 10.6.0

Main Software Functions

Setup Mode Plug & Auto Installation

PIN1 Supported,enable/disable/modify

SMS Supported

PhoneBook Supported

APN Auto Management Supported

Complete Session Statistics Supported

Field Test Data Supported

SMS and Data Service Simultaneously Operation Supported

Phone Book

vCard Version 2.1/3.0

New Contacts Supported

Edit Contacts Supported

Delete Contacts Supported

Send SMS Supported

Move between SIM card and PC Supported

SMS

Group Messages Supported

New SMS Supported

Send SMS Supported

Save SMS to Drafts Supported

Reply SMS Supported

Forward SMS Supported

Delete SMS Supported

Import from SIM/Modem to PC Supported

Additional Features

Micro-SD Card Slot Supported, Max up to 8GB

Certification

ROHS Supported

Microsoft WHQL Supported

Others Could be supported upon request

Attention For MAC OS:

1.Mac Book, Mac Book Pro, iMac, Mac Pro or Mac mini (Intel CPU)

2.Mac OSX 10.4.9 or higher, up to 10.9 or latest
