Model: AT-GS3010SFP
Description
AT-GS3010SFP 8-port+2SFP10/100/1000M Switch provides the seamless network connection. It integrates 10/100/1000Mbps Ethernet network capabilities.
AT-GS3010SFP is web smart switch, and can be configured by web based interface. Including administrator, port management, VLAN setting, each port statistics, trunking setting, QoS setting, security filter, configuration/ backup/recovery, miscellaneous, log out, and so on.
Ø Complies with IEEE802.3, IEEE 802.3u, IEEE 802.3ab standards
Ø 8 x 10/100/1000Mbps Auto-Negotiation RJ45 ports supporting Auto-MDI/MDIX
Ø Support the Console port management
Ø Supports IEEE802.3x flow control for Full-duplex Mode and backpressure for Half-duplex Mode
Ø 8K entry MAC address table of the AT-GS3010SFP with auto-learning and auto-aging
Ø Supports WEB management interface
Ø LED indicators for monitoring power, link, activity and speed
Ø Internal power adapter supply
Specification
|
AT-GS3010SFP |
||
|
Chipset |
RTL8380M+RTL8231 |
|
|
IEEE 802.3, 802.3u, 802.3ab, 802.3z, 802.3x, 802.1q, 802.1p, IEEE 802.3at, IEEE 802.3af |
||
|
10BASE-T: UTP category 5 cable (maximum 100m) 100BASE-T: UTP category 5 cable (maximum 100m) 1000Base-T: UTP category 5, 5e cable (maximum 100m) |
||
|
Number of Ports |
8 x 10/100/1000Mbps Auto-Negotiation ports |
|
|
LED indicators |
Port |
Link/Act |
|
POE |
|
|
|
Other |
Power |
|
|
Transfer Method |
Store-and-Forward |
|
|
8K |
||
|
Switching Capacity |
20 Gbps |
|
|
10Mbps: 14880pps 100Mbps: 148800pps 1000Mbps: 1488000pps |
||
|
Dimensions (L × W × H) |
280*180*44 mm |
|
|
Environment |
Operating Temperature: 0℃~40℃ Storage Temperature: -10℃~70℃ Operating Humidity: 10%~90% non-condensing Storage humidity: 5%~90% non-condensing |
|
